Gaming Monitor Power Use: 60Hz vs 144Hz & 240Hz

A high-refresh gaming monitor usually uses a little more electricity than a 60Hz display, but the refresh rate alone is often a small part of the bill. In many real setups, brightness, screen size, resolution, HDR, and GPU behavior matter more.

If you have ever looked at a gaming monitor spec sheet and wondered whether 144Hz or 240Hz will quietly raise your power bill, that concern is reasonable. Real measurements show the monitor itself may only climb by a few watts when you raise refresh rate, while a brighter picture mode or a GPU leaving low-power idle can add much more. This breakdown will help you separate the cost of smoother motion from the cost of everything else packed into modern gaming displays.

The Short Answer: High Refresh Usually Adds a Small Monitor-Side Load

Real-world monitor power measurements show that moving from 60Hz to a higher refresh rate often changes display power by only a few watts. One 34-inch ultrawide monitor measured 20W at 60Hz and 24.3W at 144Hz in a dim standard mode, which is a meaningful increase in percentage terms but still modest in absolute cost for most households.

A second set of user-reported refresh-rate comparisons lands in the same range: roughly 31.0W at 60Hz, 33.0W at 144Hz, and 35.5W at 240Hz. Using a common US electricity price, that spread works out to pennies over shorter sessions and only a small annual bump for most buyers choosing between a standard office monitor and a mainstream gaming display.

Another desktop 60Hz versus 165Hz test found about a 1W difference at idle. That does not mean every monitor behaves the same way, but it does reinforce the core buying takeaway: if two monitors are otherwise similar, refresh rate by itself is usually not the biggest factor in electricity use.

What Matters More Than Refresh Rate

For most monitor energy use, larger screen size, higher resolution, and higher brightness have a bigger effect than changing from 60Hz to 144Hz. More screen area needs more backlight, and more pixels require more processing. That is why two 27-inch monitors with different brightness ceilings or panel technologies can have a larger power gap than two otherwise similar monitors running at different refresh rates.

High brightness settings can be especially expensive. In high-brightness display design, doubling brightness can require roughly 2.5x to 3x more power, and automatic brightness controls can reduce consumption by 30% to 50% in changing room light. For buyers comparing monitors in a bright retail floor, this is an easy trap: the screen that looks punchier under showroom lighting may cost more to run at home than the refresh-rate upgrade you were worried about.

That pattern shows up in consumer plug-meter testing too. The same monitor that used 24.3W at 144Hz jumped to 57.2W in a brighter movie mode, more than doubling power without any change in panel size. If your goal is to keep a gaming setup efficient, lowering brightness one notch often saves more energy than dropping from 144Hz to 120Hz.

When High Refresh Really Does Increase Total System Power

Very high refresh-rate setups above 360Hz can change the picture because the monitor is not the only device working harder. The display electronics may draw more power, but the larger risk is that the graphics card stops sitting in a low-power state or has to render much higher frame rates to justify the panel. That is why some users see a modest monitor-only increase yet a much larger jump at the wall.

The key distinction is refresh rate versus frame rate. A 144Hz monitor does not automatically force the GPU to work harder; the GPU load rises when the system actually renders more frames, especially with sync disabled or with a game uncapped at very high FPS. For desktop use, browsing, or slower games where the GPU is not chasing 144 FPS or 240 FPS, the total power increase may stay small.

Once you start targeting extreme frame rates, cost can climb faster. One scenario in the research notes estimated that an extra 50W for an 8-hour-a-day 500Hz setup would add about 0.4 kWh per day, or roughly $23 per year at $0.16 per kWh. That is still not catastrophic, but it is enough to matter if you are choosing between a 240Hz monitor that already matches your hardware and a 500Hz model that pushes both the display and the PC harder.

Ultrawide, 1440p, 4K, and HDR Can Cost More Than the Hz Upgrade

A wider ultrawide resolution often has a larger energy impact than a simple jump from 60Hz to 144Hz because it increases the number of pixels being driven every frame. A standard 2560x1440 display shows about 3.7 million pixels, while 3440x1440 pushes nearly 5 million, or about 34% more work. That affects both the monitor electronics and, more importantly for gamers, the graphics card needed to maintain high frame rates.

The same tradeoff shows up in hands-on ultrawide ownership notes. A 3440x1440 ultrawide can make games feel more immersive, but it also makes 144 FPS harder to sustain, even on very fast hardware. For buyers comparing a flat 27-inch 1440p monitor against a 34-inch ultrawide with the same refresh rate, the wider screen is often the more important driver of total gaming power.

HDR and premium backlight systems can push power much higher still. In power-draw examples from high-end monitors, models with 4K resolution, local dimming, OLED panels, or very high peak brightness ranged far above the 20W to 35W territory many mainstream monitors occupy. That matters because a shopper can fixate on 144Hz versus 240Hz and miss the fact that a high-end HDR backlight system or a very large OLED panel may dominate the long-term electricity cost.

How to Estimate Your Yearly Monitor Cost

A simple monitor energy calculator needs only three numbers: monitor wattage, hours used per day, and your electricity price in dollars per kWh. The practical formula behind the scenes is straightforward: higher wattage and longer daily use matter more than small differences in refresh rate. If you work and game on the same display for 8 to 10 hours a day, even a 10W to 20W gap becomes more noticeable over a full year.

For a grounded example, use the measured values above. A 31W 60Hz monitor used 8 hours per day would consume about 90.5 kWh per year. A 35.5W 240Hz monitor used for the same time would consume about 103.7 kWh per year. At $0.16 per kWh, that is about $14.48 per year versus $16.59 per year, a difference of roughly $2.11 annually for the display itself.

Energy labels also help as a rough filter. Current monitor efficiency labels can look worse than buyers expect because the scale became stricter, but they still provide a useful signal when you are comparing similar sizes and use cases. If two gaming monitors fit your needs, the one with the lower active power rating or better efficiency label is usually the safer long-term pick, especially if you leave it on for work, streaming, and gaming every day.

Comparison Table: Where the Power Difference Usually Comes From

Factor	Typical effect on monitor power	Effect on total gaming setup	Buying guidance
60Hz to 144Hz	Usually small, often a few watts	Small to moderate	Worth it for most gamers if your GPU can feed it
144Hz to 240Hz	Usually small to modest	Moderate if FPS target rises a lot	Best for competitive play, less compelling for casual use
240Hz to 360Hz+	Can rise more unpredictably	Can become significant	Buy only if your games and hardware justify it
Higher brightness	Often large	Mostly monitor-side	Lower brightness first if efficiency matters
HDR / high-end backlight systems / OLED peaks	Can be very large	Mostly monitor-side	Check real measured power, not just marketing specs
1440p to ultrawide 3440x1440	Moderate	Often large because GPU load rises	Great for immersion, but budget for more power and GPU demand
27-inch to 34-inch+	Moderate to large	Mostly monitor-side	Compare active wattage before buying

Practical Next Steps

If you want smoother gameplay without wasting money on electricity, start with a 120Hz to 144Hz sweet spot. That range gives a clear improvement in motion clarity and input latency over 60Hz, while avoiding some of the diminishing returns and higher system demands that show up at 240Hz, 360Hz, and beyond.

Use this checklist before you buy or tune a monitor:

Match refresh rate to the FPS your PC can actually sustain in the games you play most.
Compare active wattage and brightness specs, not just refresh rate.
Treat ultrawide, 4K, HDR, and very high peak brightness as bigger power variables than 60Hz versus 144Hz alone.
Measure wall power in your own setup if you are choosing between 240Hz and 360Hz+.
Lower brightness and cap FPS near refresh rate to cut the most waste quickly.
Use adaptive sync so the monitor and GPU stay efficient when frame rate varies.

FAQ

Q: Does a 144Hz monitor use much more electricity than a 60Hz monitor?

A: Usually no. In many examples, the monitor itself uses only a few watts more at 144Hz than at 60Hz. The bigger difference often comes from brightness settings, HDR, and whether your GPU is rendering far more frames.

Q: Is 240Hz expensive to run compared with 144Hz?

A: For the monitor alone, the cost difference is often still modest. The larger expense shows up when a 240Hz setup encourages higher FPS targets, which can raise graphics card power use during gaming.

Q: What should I check first if I want an efficient gaming monitor?

A: Check active power rating, screen size, resolution, brightness, and HDR capability before worrying too much about refresh rate. Among otherwise similar monitors, brightness and panel class often explain more of the electric bill than the jump from 60Hz to 144Hz.
